PayU With Django Rest Framework

Technology Blogs

PayU is a payment gateway used for secured payment transactions, PayU is available in 200+ countries across the globe that’s the reason it has a number of customers, and also it provides the best services to their customers and it gives service at a reasonable cost. The blog contains different steps so that we can understand how to use PayU using Django, we are going to add design templates with payment logic and PayU.

Different steps required to implement PayU using Django are given below

Library required to use PayU in Django
PayU dashboard and setup connectivity
Creating templates
Creating a view for checkout
Handling Success
Handling Failure

1. Library required to use PayU in Django

To integrate PayU with Django, you need to install paywix with the latest version 1.3.0 The following command is used to install PayU in Django.

pip install paywix

2. PayU dashboard and setup connectivity

In the PayU dashboard as we are now developing gateway, we need to switch live mode to test mode as shown in the below image.

To setup connectivity you need different keys of PayU, using PayU you require a merchant key and merchant salt key, and to get these keys you need to create your account and get it and then you need to add these details to settings.py of your project and to get the credentials you need to follow the below steps.

Sign in to PayU
Go to Integration help
Click on the credential
Get a publishable key and secret key as given in the below imagef

keys

Adding credentials to Django settings
Create an object with PAYU_CONFIG and inside that object, we need to add keys and mode. Mode means in which mode we are working test or live,

PAYU_CONFIG = {

    "merchant_key": *********,

    "merchant_salt":*********, ,

    "mode": "test",

   }

3. Creating templates

After adding keys to Django settings you need to create templates to design a payment gateway.to use templates in your project add templates in Django setting as shown below

TEMPLATES = [

   {

       'BACKEND': 'django.template.backends.django.DjangoTemplates',

       'DIRS': [BASE_DIR+'/templates'],

       'APP_DIRS': True,

       'OPTIONS': {

           'context_processors': [

               'django.template.context_processors.debug',

               'django.template.context_processors.request',

               'django.contrib.auth.context_processors.auth',

               'django.contrib.messages.context_processors.messages',

           ],

       },

   },

]

After that, you need to create a folder in the Django project as shown below

Firstly we need to create the design of a home page, the home page contains simple UI with pay button and price

<html>

  <head>

      <title>Loading...</title>

  </head>

<body>

<h1>Hello</h1>

<a href="{% url 'payu_demo' %}"> Pay_demo</a>

</body>


  </html>

After creating a template for the payment gateway home page we also need to create a template for payu checkout as shown below.

<html>

  <head>

      <title>Loading...</title>

  </head>


  <body onload="document.payuForm.submit()">

      <form action={{ posted.action }} method="post" name="payuForm">

          {% csrf_token %}

          <input type="hidden" name="key" value="{{posted.key}}" />

          <input type="hidden" name="hash_string" value="{{ posted.hash_string }}" />

          <input type="hidden" name="hash" value="{{ posted.hashh }}" />

          <input type="hidden" name="posted" value="{{ posted }}" />

          <input type="hidden" name="txnid" value="{{ posted.txnid }}" />

          <input type="hidden" name="amount" value="{{ posted.amount|default:'' }}" /></td>

          <input type="hidden" name="firstname" id="firstname" value="{{ posted.firstname|default:'' }}" /></td>

          <input type="hidden" name="email" id="email" value="{{ posted.email|default:'' }}" /></td>

          <input type="hidden" name="phone" value="{{ posted.phone|default:'' }}" /></td>

          <textarea type="hidden" name="productinfo" style="display:none;">{{ posted.productinfo|default:'' }}</textarea>

          </td>

          <input type="hidden" name="surl" value="{{ posted.surl }}" size="64" /></td>

          <input type="hidden" name="furl" value="{{ posted.furl }}" size="64" /></td>

          <input type="hidden" name="service_provider" value="{{posted.service_provider}}" size="64" />

          <input type="hidden" name="lastname" id="lastname" value="{{ posted.lastname }}" /></td>

          <input type="hidden" name="address1" value="{{ posted.address1 }}" /></td>

          <input type="hidden" name="address2" value="{{ posted.address2 }}" /></td>

          <input type="hidden" name="city" value="{{ posted.city }}" /></td>

          <input type="hidden" name="state" value="{{ posted.state }}" /></td>

          <input type="hidden" name="country" value="{{ posted.country }}" /></td>

          <input type="hidden" name="zipcode" value="{{ posted.zipcode }}" /></td>

          <input type="hidden" name="udf1" value="{{ posted.udf1 }}" /></td>

          <input type="hidden" name="udf2" value="{{ posted.udf2 }}" /></td>

          <input type="hidden" name="udf3" value="{{ posted.udf3 }}" /></td>

          <input type="hidden" name="udf4" value="{{ posted.udf4 }}" /></td>

          <input type="hidden" name="udf5" value="{{ posted.udf5 }}" /></td>

      </form>

  </body>

  </html>

4. Creating a view for checkout

Creating a view for checkout is a simple task. In this task, we have to send data html template only by using render method and need to send user details and hash key to template that we have created for payment gateway design.

class PayuDemoAPiView(GenericAPIView):

    """

       Class for creating API view for Payment.

       """


    def get(self, request):

        """

        Function for Payment.

        """

        data = {'amount': '10',

                'firstname': test,

                'email': 'test@gmail.com',

                'phone': '1122334455', 'productinfo': 'test',

                'lastname': 'test', 'address1': 'test',

                'address2': 'test', 'city': 'test',

                'state': 'test', 'country': 'test',

                'zipcode': 'tes'

                }


        data.update({"txnid": "123456789"})

        payu_data = payu.transaction(**data)

        return render(request, 'payu_checkout.html', {"posted": payu_data})

Hask hay is generated by using the PayU transaction method and then we can pass it to the checkout template.

5. Handling a success

Handling success is an important step in the payment process. In this process after the transaction successfully completed then we need to show all transaction details and for that, we need to call API view of a successful transaction.

Firstly we need to handle URL so that after a successful transaction success API view is called. So for that, we need to add URL details in settings.py in PAYU_CONFIG as below

PAYU_CONFIG = {

    "merchant_key": "********",

    "merchant_salt": "********",

    "mode": "test",

    "success_url": "http://127.0.0.1:8000/success",

}

After calling success API view we need to add API view for success as below

class PayuSuccessAPiView(GenericAPIView):

    """

       Class for creating API view for Payment Success.

       """

    serializer_class = TransactionDetailsSerializer


    def post(self, request):

        """

        Function for Payment Success.

        """

        serializer = self.get_serializer(data=request.data)

        data = {k: v[0] for k, v in dict(request.data).items()}

        if serializer.is_valid():

            serializer.save()

        response = payu.verify_transaction(data)

        return JsonResponse(response)

After successful payment, we have also stored payment transaction details to the database using serializers as shown in the above code.

6. Handling a failure

Handling failure is the last step in the transaction process. In this process after the transaction failed then we need to call api view of transaction failure.

Firstly we need to handle url so that after transaction failure api view is called.So for that we need to add url details in settings.py in PAYU_CONFIG as below

PAYU_CONFIG = {

    "merchant_key": "********",

    "merchant_salt": "********",

    "mode": "test",

    "failure_url": "http://127.0.0.1:8000/failure",

}

After calling failure api view we need to add api view for failure as below

class PayuFailureAPiView(GenericAPIView):

    """

       Class for creating API view for Payment Failure.

       """


    @csrf_exempt

    def post(self, request):

        """

        Function for Payment Failure.

        """

        data = {k: v[0] for k, v in dict(request.data).items()}

        response = payu.verify_transaction(data)

        return JsonResponse(response)

Here, we have also added the PayU method to .verify the transaction to check whether transactions are failed or not

Conclusion

This blog covered how to design a payment gateway with good UI and how we can add different fields in it, also how to use templates in Django, and it also gives us ideas about how to create checkout and generate hash keys and also covered how to handle transaction success and failure.

Code snippet

view.py

from django.http import JsonResponse

from django.shortcuts import render

from django.views.decorators.csrf import csrf_exempt

from django.conf import settings

from paywix.payu import Payu

from rest_framework.generics import GenericAPIView


from .serializers import TransactionDetailsSerializer


payu_config = settings.PAYU_CONFIG

merchant_key = payu_config.get('merchant_key')

merchant_salt = payu_config.get('merchant_salt')

surl = payu_config.get('success_url')

furl = payu_config.get('failure_url')

mode = payu_config.get('mode')


payu = Payu(merchant_key, merchant_salt, surl, furl, mode)


def home(request):

    print("request", request)


    return render(request, 'home.html')


class PayuDemoAPiView(GenericAPIView):

    """

       Class for creating API view for Payment.

       """

    def get(self, request):

        """

        Function for Payment.

        """

        data = {'amount': '10',

                'firstname': 'rishikesh',

                'email': 'rishidevkate@gmail.com',

                'phone': '7276034203', 'productinfo': 'test',

                'lastname': 'test', 'address1': 'test',

                'address2': 'test', 'city': 'test',

                'state': 'test', 'country': 'test',

                'zipcode': 'tes'

                }


        data.update({"txnid": "123456789"})

        payu_data = payu.transaction(**data)

        return render(request, 'payu_checkout.html', {"posted": payu_data})


class PayuSuccessAPiView(GenericAPIView):

    """

       Class for creating API view for Payment Success.

       """

    serializer_class = TransactionDetailsSerializer


    def post(self, request):

        """

        Function for Payment Success.

        """

        serializer = self.get_serializer(data=request.data)


        data = {k: v[0] for k, v in dict(request.data).items()}

        if serializer.is_valid():

            serializer.save()

        response = payu.verify_transaction(data)

        return JsonResponse(response)


class PayuFailureAPiView(GenericAPIView):

    """

       Class for creating API view for Payment Failure.

       """


    @csrf_exempt

    def post(self, request):

        """

        Function for Payment Failure.

        """

        data = {k: v[0] for k, v in dict(request.data).items()}

        response = payu.verify_transaction(data)

        return JsonResponse(response)

templates/checkout.html

 <html>

  <head>

      <title>Loading...</title>

  </head>


  <body onload="document.payuForm.submit()">

      <form action={{ posted.action }} method="post" name="payuForm">

          {% csrf_token %}

          <input type="hidden" name="key" value="{{posted.key}}" />

          <input type="hidden" name="hash_string" value=

                  "{{ posted.hash_string }}" />

          <input type="hidden" name="hash" value="{{ posted.hashh }}"

          />

          <input type="hidden" name="posted" value="{{ posted }}" />

          <input type="hidden" name="txnid" value="{{ posted.txnid }}"

          />

          <input type="hidden" name="amount" value="{{ posted.amount

          |default:'' }}" /></td>

          <input type="hidden" name="firstname" id="firstname"

                 value="{{ posted.firstname|default:'' }}"

          /></td>

          <input type="hidden" name="email" id="email" value=

                  "{{ posted.email|default:'' }}"

          /></td>

          <input type="hidden" name="phone" value="

          {{ posted.phone|default:'' }}" /></td>

          <textarea type="hidden" name="productinfo"

                    style="display:none;">{{

              posted.productinfo|default:

              '' }}

          </textarea>

          </td>

          <input type="hidden" name="surl" value="{{ posted.surl }}"

                 size="64" /></td>

          <input type="hidden" name="furl" value="{{ posted.furl }}"

                 size="64" /></td>

          <input type="hidden" name="service_provider" value="

          {{posted.service_provider}}"

                 size="64" />

          <input type="hidden" name="lastname" id="lastname"

                 value="{{ posted.lastname }}"

          /></td>

          <input type="hidden" name="address1" value="

          {{ posted.address1 }}" /></td>

          <input type="hidden" name="address2" value="

          {{ posted.address2 }}" /></td>

          <input type="hidden" name="city" value="

          {{ posted.city }}" /></td>

          <input type="hidden" name="state" value="

          {{ posted.state }}" /></td>

          <input type="hidden" name="country" value="

          {{ posted.country }}" /></td>

          <input type="hidden" name="zipcode" value="

          {{ posted.zipcode }}" /></td>

          <input type="hidden" name="udf1" value="

          {{ posted.udf1 }}" /></td>

          <input type="hidden" name="udf2" value="

          {{ posted.udf2 }}" /></td>

          <input type="hidden" name="udf3" value="

          {{ posted.udf3 }}" /></td>

          <input type="hidden" name="udf4" value="

          {{ posted.udf4 }}" /></td>

          <input type="hidden" name="udf5" value="

          {{ posted.udf5 }}" /></td>

      </form>

  </body>

  </html>

Rishikesh D

Software Engineer

Rishikesh is a Full-stack developer with 3+ years of experience. He has experience in web technologies like AngularJS, ReactJS. His expertise is building Python integrated web applications, creating REST APIs with well-designed, testable and efficient and optimized code. He loves to learn new technologies.

Service
Career

Let's create something together!
We’re looking for the best. Are you in?

Mindbowser and team are professional, talented and very responsive. They got us through a challenging situation with our IOT product successfully. They will be our go to dev team going forward.

Dan Munro

Founder, Cascada

Anthony Lewis

Co-Founder, Emerge

The team is great to work with. Very professional, on task, and efficient.

Matthew Holsclaw

Founder, PeriopMD

I can not express enough how pleased we are with the whole team. From the first call and meeting, they took our vision and ran with it. Communication was easy and everyone was flexible to our schedule. I’m excited to...

Angela Boudreaux

Founder, SafeZone Safety Systems

Mindbowser has truly been foundational in my journey from concept to design and onto that final launch phase.

Jovan Pizarro

CEO, KickSnap

We had very close go live timeline and MindBowser team got us live a month before.

Shaz Khan

CEO, BuyNow WorldWide

If you want a team of great developers, I recommend them for the next project.

Vladimir Kudryavtsev

Founder, Teach Reach

Mindbowser built both iOS and Android apps for Mindworks, that have stood the test of time. 5 years later they still function quite beautifully. Their team always met their objectives and I'm very happy with the end result. Thank you!

Bart Mendel

Founder, Mindworks

Our CISO was extremely impressed by Mindbowser’s work. It is pretty rare to see this kind of clean security report so early in the company’s journey. Huge Thank you for the disciplined approach here.

Kushal Shah

Founder, TrestleIQ

Mindbowser has delivered a much better quality product than our previous tech vendors. Our product is stable and passed Well Architected Framework Review from AWS.

Pankaj Parashar

CEO, PurpleAnt

The flexibility and capacity of the Mindbower staff has been impressive.

Matthew Amsden

CEO, ProofPilot

I am happy to share that we got USD 10k in cloud credits courtesy of our friends at Mindbowser. Thank you Pravin and Ayush, this means a lot to us.

Sudheer Bandaru

CTO, Shortlist

Mindbowser is one of the reasons that our app is successful. These guys have been a great team.

Dave Dubier

Founder & CEO, MangoMirror

Kudos for all your hard work and diligence on the Telehealth platform project. You made it possible.

Joyce Nwatuobi

CEO, ThriveHealth

Mindbowser helped us build an awesome iOS app to bring balance to people’s lives.

Addie Wootten

CEO, SMILINGMIND

They were a very responsive team! Extremely easy to communicate and work with!

Kristen M.

Founder & CEO, TotTech

We’ve had very little-to-no hiccups at all—it’s been a really pleasurable experience.

Chacko Thomas

Co-Founder, TEAM8s

Mindbowser was very helpful with explaining the development process and started quickly on the project.

Hieu Le

Executive Director of Product Development, Innovation Lab

The greatest benefit we got from Mindbowser is the expertise. Their team has developed apps in all different industries with all types of social proofs.

Alex Gobel

Co-Founder, Vesica

Mindbowser is professional, efficient and thorough.

MacKenzie Richter

Consultant, XPRIZE

Very committed, they create beautiful apps and are very benevolent. They have brilliant Ideas.

Laurie Mastrogiani

Founder, S.T.A.R.S of Wellness

MindBowser was great; they listened to us a lot and helped us hone in on the actual idea of the app. They had put together fantastic wireframes for us.

Bennet Gillogly

Co-Founder, Flat Earth

Ayush was responsive and paired me with the best team member possible, to complete my complex vision and project. Could not be happier.

Katie Taylor

Founder, Child Life On Call

As a founder of a budding start-up, it has been a great experience working with Mindbower Inc under Ayush's leadership for our online digital platform design and development activity.

Radhika Kotwal

Founder, Courtyardly

The team from Mindbowser stayed on task, asked the right questions, and completed the required tasks in a timely fashion! Strong work team!

Michael Wright

CEO, SDOH2Health LLC

Mindbowser was easy to work with and hit the ground running, immediately feeling like part of our team.

George Hodulik

CEO, Stealth Startup

Mindbowser was an excellent partner in developing my fitness app. They were patient, attentive, & understood my business needs. The end product exceeded my expectations. Thrilled to share it globally.

Jirina Harastova

Owner, Phalanx

Mindbowser's expertise in tech, process & mobile development made them our choice for our app. The team was dedicated to the process & delivered high-quality features on time. They also gave valuable industry advice. Highly recommend them for app development...

Marty Betz

Co-Founder, Fox&Fork
